TYCP
王牌电机
| 状态： | |
|---|---|
| 数量： | |
| 同步转速 | ||||
| 3000r/min 200HZ | 1500r／min 100HZ或150HZ | |||
| 型号规格 | 极数 | 功率(KW) | 极数 | 功率(KW) |
| TYCP132S1 | 8 | 7.5 | / | / |
| TYCP132S2 | 11 | |||
| TYCP132S3 | 15 | |||
| TYCP132M | 18.5 | |||
| TYCP160M1 | 8 | 22 | 8 | 15 |
| TYCP160M2 | 30 | |||
| TYCP160L | / | / | 18.5 | |
| TYCP180M1 | 8 | 37 | 8 | 22 |
| TYCP180M2 | 45 | |||
| TYCP180L | / | / | 30 | |
| TYCP200L1 | 8 | 55 | 8 | 37 |
| TYCP200L2 | 45w | |||
| TYCP225S | 8 | 75 | / | / |
| TYCP225M | 90 | 55 | ||
| TYCP250M1 | 8 | 110 | 8 | 75 |
| TYCP250M2 | 132 | 90 | ||
| TYCP250M3 | / | 55 | ||
| TYCP280S1 | 8 | 160 | 8/12 | 110 |
| TYCP280S2 | 185 | |||
| TYCP280M1 | 200 | 132 | ||
| TYCP280M2 | 220 | |||
| TYCP315S1 | 8 | 160 | 8/12 | 160 |
| TYCP315S2 | 185 | 8 | 185 | |
| TYCP315M1 | 200 | 200 | ||
| TYCP315M2 | 220 | 220 | ||
| TYCP315L | 250 | 250 | ||
| TYCP355M1 | 8 | 280 | 8 | 280 |
| TYCP355M2 | 315 | 315 | ||
| TYCP355M3 | 355 | 355 | ||
| 同步转速1500r/min | ||||||||
| 型号规格 | 功率kW | 额定电流 A | 频率 HZ | 转速 RPM | 效率 % | 额定转矩 N.m | 噪声 dB(A) | 重量 KG |
| TYCP160M-8 | 15 | 25 | 100 | 1500 | 94 | 95.5 | 75 | 125 |
| TYCP160L-8 | 18.5 | 31 | 100 | 1500 | 94.3 | 118 | 75 | 148 |
| TYCP180M-8 | 22 | 37 | 100 | 1500 | 94.7 | 140 | 76 | 180 |
| TYCP180L-8 | 30 | 50 | 100 | 1500 | 95 | 191 | 76 | 220 |
| TYCP200L1-8 | 37 | 61 | 100 | 1500 | 95.3 | 236 | 79 | 245 |
| TYCP200L2-8 | 45 | 74 | 100 | 1500 | 95.6 | 287 | 79 | 270 |
| TYCP225M-8 | 55 | 91 | 100 | 1500 | 95.8 | 350 | 81 | 315 |
| TYCP250M1-8 | 75 | 124 | 100 | 1500 | 96 | 478 | 83 | 460 |
| TYCP250M2-8 | 90 | 149 | 100 | 1500 | 96.2 | 573 | 83 | 500 |
| TYCP250M3-8 | 55 | 91 | 100 | 1500 | 96.8 | 350 | 83 | 390 |
| TYCP280S-8 | 110 | 183 | 100 | 1500 | 96.4 | 700 | 86 | 592 |
| TYCP280M-8 | 132 | 219 | 100 | 1500 | 96.6 | 840 | 86 | 644 |
| TYCP280S-12 | 110 | 183 | 150 | 1500 | 96.4 | 700 | 86 | 550 |
| TYCP280M-12 | 132 | 219 | 150 | 1500 | 96.6 | 840 | 86 | 620 |
| TYCP315S-12 | 160 | 265 | 150 | 1500 | 96.8 | 1018 | 93 | 780 |
| TYCP315S1-8 | 160 | 259 | 100 | 1500 | 97.1 | 1018 | 93 | 830 |
| TYCP315S2-8 | 185 | 300 | 100 | 1500 | 97.1 | 1178 | 93 | 912 |
| TYCP315M1-8 | 200 | 325 | 100 | 1500 | 97.2 | 1273 | 93 | 1060 |
| TYCP315M2-8 | 220 | 365 | 100 | 1500 | 97.2 | 1400 | 93 | 1070 |
| TYCP315L-8 | 250 | 405 | 100 | 1500 | 97.2 | 1591 | 93 | 1274 |
| TYCP355M1-8 | 280 | 455 | 100 | 1500 | 97.3 | 1782 | 98 | 1515 |
| TYCP355M2-8 | 315 | 515 | 100 | 1500 | 97.3 | 2005 | 98 | 1641 |
| TYCP355M3-8 | 355 | 580 | 100 | 1500 | 97.3 | 2260 | 98 | 1872 |
| 同步转速3000r/min | ||||||||
| 型号规格 | 功率 KW | 颜定电流 A | 频率 HZ | 转速 RPM | 效率 % | 额定转矩 N.m | 噪声 dB(A) | 重量 KG |
| TYCP132S1-8 | 7.5 | 13.2 | 200 | 3000 | 94.5 | 24 | 80 | 60 |
| TYCP132S2-8 | 11 | 19.5 | 200 | 3000 | 95 | 35 | 80 | 65 |
| TYCP132S3-8 | 15 | 26.3 | 200 | 3000 | 95.3 | 48 | 80 | 70 |
| TYCP132M-8 | 18.5 | 32.5 | 200 | 3000 | 95.6 | 59 | 80 | 85 |
| TYCP160M1-8 | 22 | 38.5 | 200 | 3000 | 95.9 | 70 | 86 | 110 |
| TYCP160M2-8 | 30 | 52 | 200 | 3000 | 96.1 | 96 | 86 | 120 |
| TYCP180M1-8 | 37 | 64 | 200 | 3000 | 96.3 | 118 | 89 | 155 |
| TYCP180M2-8 | 45 | 77 | 200 | 3000 | 96.4 | 143 | 89 | 165 |
| TYCP200L-8 | 55 | 94 | 200 | 3000 | 96.5 | 175 | 92 | 215 |
| TYCP225S-8 | 75 | 127 | 200 | 3000 | 96.6 | 239 | 92 | 260 |
| TYCP225M-8 | 90 | 152 | 200 | 3000 | 96.7 | 287 | 92 | 295 |
| TYCP250M1-8 | 110 | 185 | 200 | 3000 | 96.7 | 350 | 93 | 370 |
| TYCP250M2-8 | 132 | 222 | 200 | 3000 | 96.7 | 420 | 93 | 410 |
| TYCP280S1-8 | 160 | 270 | 200 | 3000 | 96.8 | 509 | 94 | 551 |
| TYCP280S2-8 | 185 | 312 | 200 | 3000 | 96.8 | 589 | 94 | 574 |
| TYCP280M1-8 | 200 | 338 | 200 | 3000 | 96.9 | 637 | 94 | 608 |
| TYCP280M2-8 | 220 | 372 | 200 | 3000 | 96.9 | 700 | 94 | 628 |
| TYCP315S1-8 | 160 | 270 | 200 | 3000 | 96.8 | 509 | 99 | 832 |
| TYCP315S2-8 | 185 | 312 | 200 | 3000 | 96.8 | 589 | 99 | 965 |
| TYCP315M1-8 | 200 | 338 | 200 | 3000 | 96.9 | 637 | 99 | 1060 |
| TYCP315M2-8 | 200 | 372 | 200 | 3000 | 96.9 | 700 | 99 | 1134 |
| TYCP315L-8 | 250 | 435 | 200 | 3000 | 96.9 | 796 | 99 | 1230 |
| TYCP355M1-8 | 280 | 455 | 200 | 3000 | 97.3 | 891 | 101 | 1335 |
| TYCP355M2-8 | 315 | 515 | 200 | 3000 | 97.3 | 1002 | 101 | 1350 |
| TYCP355M3-8 | 355 | 580 | 200 | 3000 | 97.3 | 1130 | 101 | 1510 |
| 同步转速1000r/min | ||||||||
| 型号规格 | 功率 | 额定电流 A | 频率 HZ | 转速 RPM | 效率 % | 顺定转矩 N.m | 噪声 dB(A) | 重量 KG |
| TYCP132S-8 | 3 | 5.4 | 66.7 | 1000 | 91.8 | 29 | 69 | 58 |
| TYCP132M1-8 | 4 | 7.1 | 66.7 | 1000 | 92.7 | 38 | 69 | 71 |
| TYCP132M2-8 | 5.5 | 9.2 | 66.7 | 1000 | 93.4 | 52 | 69 | 82 |
| TYCP160M-8 | 7.5 | 13 | 66.7 | 1000 | 94 | 72 | 73 | 107 |
| TYCP160L-8 | 11 | 19.5 | 66.7 | 1000 | 94.5 | 105 | 73 | 136 |
| TYCP180L-8 | 15 | 25 | 66.7 | 1000 | 94.9 | 143 | 75 | 182 |
| TYCP200L1-8 | 18.5 | 31 | 66.7 | 1000 | 95.3 | 177 | 76 | 215 |
| TYCP200L2-8 | 22 | 37 | 66.7 | 1000 | 95.6 | 210 | 76 | 232 |
| TYCP225M-8 | 30 | 50 | 66.7 | 1000 | 95.8 | 286 | 79 | 280 |
| TYCP250M-8 | 37 | 61 | 66.7 | 1000 | 96 | 353 | 81 | 360 |
| TYCP280S-8 | 45 | 74 | 66.7 | 1000 | 96.2 | 430 | 85 | 483 |
| TYCP280M-8 | 55 | 91 | 66.7 | 1000 | 96.3 | 525 | 85 | 510 |
| TYCP315S-8 | 75 | 124 | 66.7 | 1000 | 96.4 | 716 | 87 | 855 |
| TYCP315M-8 | 90 | 149 | 66.7 | 1000 | 96.5 | 859 | 87 | 915 |
| TYCP315L1-8 | 110 | 183 | 66.7 | 1000 | 96.6 | 1050 | 87 | 980 |
| TYCP315L2-8 | 132 | 219 | 66.7 | 1000 | 96.7 | 1260 | 87 | 1045 |
| 同步转速1500r/min | ||||||||
| 型号规格 | 功率 KW | 额定电流 A | 频率 HZ | 转速 RPM | 效率 % | 颜定转矩 N.m | 噪声 dB(A) | 重量 KG |
| TYCP132S-8 | 5.5 | 9.2 | 100 | 1500 | 92.1 | 35 | 71 | 70 |
| TYCP132M1-8 | 7.5 | 13 | 100 | 1500 | 92.6 | 47.8 | 71 | 78 |
| TYCP132M2-8 | 9 | 15.6 | 100 | 1500 | 93 | 57.3 | 71 | 83 |
| TYCP160M-8 | 11 | 19.5 | 100 | 1500 | 93.6 | 70 | 75 | 107 |
| TYCP160L-8 | 15 | 25 | 100 | 1500 | 94 | 95.5 | 75 | 126 |
| TYCP180M-8 | 18.5 | 31 | 100 | 1500 | 94.3 | 118 | 76 | 155 |
| TYCP180L-8 | 22 | 37 | 100 | 1500 | 94.7 | 140 | 76 | 182 |
| TYCP200L1-8 | 30 | 50 | 100 | 1500 | 95 | 191 | 79 | 230 |
| 同步转速1500r/min | ||||||||
| 型号规格 | 功率 KW | 额定电流 A | 频率 HZ | 转速 RPM | 效率 % | 额定转矩 N.m | 噪声 dB(A) | 重量 KG |
| TYCP200L2-8 | 37 | 61 | 100 | 1500 | 95.3 | 236 | 79 | 233 |
| TYCP225S-8 | 37 | 61 | 100 | 1500 | 95.3 | 236 | 81 | 236 |
| TYCP225M-8 | 45 | 74 | 100 | 1500 | 95.6 | 287 | 81 | 280 |
| TYCP250M-8 | 55 | 91 | 100 | 1500 | 95.8 | 350 | 83 | 360 |
| TYCP280S-8 | 75 | 124 | 100 | 1500 | 96 | 478 | 86 | 483 |
| TYCP280M-8 | 90 | 149 | 100 | 1500 | 96.2 | 573 | 86 | 513 |
| TYCP315S-8 | 110 | 183 | 100 | 1500 | 96.4 | 700 | 93 | 829 |
| TYCP315M-8 | 132 | 219 | 100 | 1500 | 96.6 | 840 | 93 | 892 |
| TYCP315L-8 | 160 | 259 | 100 | 1500 | 97.1 | 1018 | 93 | 947 |
| 同步转速3000r/min | ||||||||
| 型号规格 | 功率 KW | 额定电流 A | 频率 HZ | 转速 r/min | 效率 % | 额定转矩 N.m | 噪声 dB(A) | 重量 Kg |
| TYCP132S1-8 | 5.5 | 9.7 | 200 | 3000 | 94 | 17.5 | 80 | 53 |
| TYCP132S2-8 | 7.5 | 13.2 | 200 | 3000 | 94.5 | 24 | 80 | 56 |
| TYCP160M1-8 | 11 | 19.5 | 200 | 3000 | 95 | 35 | 86 | 92 |
| TYCP160M2-8 | 15 | 26.3 | 200 | 3000 | 95.3 | 48 | 86 | 101 |
| TYCP160L-8 | 18.5 | 32.5 | 200 | 3000 | 95.6 | 59 | 86 | 113 |
| TYCP180M-8 | 22 | 38.5 | 200 | 3000 | 95.9 | 70 | 89 | 130 |
| TYCP200L1-8 | 30 | 52 | 200 | 3000 | 96.1 | 96 | 92 | 191 |
| TYCP200L2-8 | 37 | 64 | 200 | 3000 | 96.3 | 118 | 92 | 197 |
| TYCP225M-8 | 45 | 77 | 200 | 3000 | 96.4 | 143 | 92 | 234 |
| TYCP250M-8 | 55 | 94 | 200 | 3000 | 96.5 | 175 | 93 | 304 |
| TYCP280S-8 | 75 | 127 | 200 | 3000 | 96.6 | 239 | 94 | 387 |
| TYCP280M-8 | 90 | 152 | 200 | 3000 | 96.7 | 287 | 94 | 436 |
| TYCP315S-8 | 110 | 185 | 200 | 3000 | 96.7 | 350 | 99 | 705 |
| TYCP315M-8 | 132 | 222 | 200 | 3000 | 96.7 | 420 | 99 | 750 |
| TYCP315L-8 | 160 | 270 | 200 | 3000 | 96.8 | 509 | 99 | 848 |
